Set Up Persisted Datasets

Let's see how to actually set up your first Persisted Dataset. In your Rock instance, go to Admin Tools > CMS Configuration > Persisted Datasets and create a new dataset. You’ll see the screen pictured below.

  1. Name - Choose a memorable name to use for organizing your Persisted Datasets.
  2. Access Key - The Access Key uniquely identifies the dataset. This will be the key to use when using the
  3. Description - Include a note about the information you’re storing and where it’s being used. Your future self will thank you for providing an informative description.
  4. Build Script - Provide the Lava Template to use for building the JSON that will be used as the cached dataset object.
  5. Enabled Lava Commands - Use these settings to control what code can run inside of your build script.
  6. Persistence Schedule - If enabled, your dataset will update on a persisted schedule. Choose one of the following types:
    1. Interval: Saves the cached dataset at a regular cadence, such as every 12 hours or every 3 days.
    2. Schedule: Sets specific days and times to rebuild the dataset, like M/W/F at 3 a.m. Ideal for large data volumes.
  7. Memory Cache Duration - Because Persisted Datasets are generally stored in memory, the duration allows you to automatically remove a dataset from memory after the specified number of hours. For example, if you were to set the field to “24” and the dataset was not accessed for over 24 hours, the data would be removed from memory. This frees up memory for other tasks and keeps Rock running fast. This is a sliding timeline, so each time the object is read the counter will reset. You can also leave this field blank to not cache the object in memory, which means it will be deserialized into the object on each request (still fast).
  8. Entity Type - The JSON object will be associated with the Entity Type selected here.
  9. Allow Manual Refresh - The JSON object will be associated with the Entity Type selected here.
  10. Expires on - If you need to force a dataset to use the most recent data, enable this setting and Rock will add a button to the list view grid to manually update data.

Building Persisted Dataset Lava

The Persisted Dataset Build Script is Lava that has been specifically formatted to output as JSON. You’ll need to format your Build Script to create properly formatted JSON that Rock can then deserialize. So, when you’re creating a Build Script using Lava, keep a few things in mind:

  • When outputting values use the ToJSON filter, which automatically sanitizes and formats your output. For example, "Name": {{ item.Name | ToJSON }} will output "Name": "Phoenix Campus".
  • You’ll need to add commas between values to create valid JSON.
  • Your build script is compiled once, and the Lava should not be customized per user.
Example Build Script
[
{%- assign slots = '140' | FromCache:'DefinedType' -%}
    {%- for item in slots.DefinedValues -%}
        {
            "Id": {{ item.Id | ToJSON }},
            "Slot": {{ item.Value | ToJSON }},
            "SlotDay": {{ item | Attribute:'Day' | ToJSON }},
            "SlotTime": {{ item | Attribute:'Time' | ToJSON }},
            "SlotDateTime": {{ item | Attribute:'DateTime' | ToJSON }},
            "SlotIsSchedulable": {{ item | Attribute:'IsSchedulable' | ToJSON }},
            "SlotLength": {{ item | Attribute:'Length' | ToJSON }},
            "SlotDateTime": {{ item | Attribute:'DateTime' | ToJSON }}
        }{%- unless forloop.last -%},{%- endunless -%}
    {%- endfor -%}
]

Now that you know a little bit more about how Persisted Datasets work, let’s take a look at a specific example. A good use case is displaying the output of timeslots for a conference. From the example pictured below, there are a few details we want to point out.

  1. Name - We set the Name to “Conference Schedule Slots” so we can easily identify what this Persisted Dataset is used for.
  2. Access Key - Like the Name, the Access Key “conferenceslots” makes it easy to identify the purpose of this Persisted Dataset. The Access Key and Name don’t need to be identical but should be closely related.
  3. Refresh Interval - This script will refresh every hour, ensuring up-to-date information around the clock.
  4. Expires On - The date we set here is the last date of our conference, since we won’t need this after our conference ends.

Given the example Build Script pictured above, you could use the Lava shown below to output to your page:

{%- assign slots = 'conferenceslots' | PersistedDataset -%}
<ul>
{%- for item in slots -%}
  <li>{{ item.Slot }} ({{ item.SlotTime }} minutes) - {{ item.SlotDateTime }}</li>
{%- endfor -%}
</ul>
